Google Cloud Platform
ZenPacks.zenoss.GoogleCloudPlatform

The Google Cloud Platform ZenPack adds support for monitoring resources deployed in Google Cloud.
Currently the following services are supported.
Compute Engine (GCE)
Kubernetes Engine (GKE)
Cloud Dataflow
Cloud Functions
Cloud Storage
BigTable
Support
This ZenPack is developed and supported by Virtana. Enterprise support is available to Virtana customers with an active subscription or support agreement. ZenPacks are available at delivery.zenoss.com. To request more information about this or any other ZenPack, contact Virtana.
Releases
Version 1.2.2
Released: 2026-08-12
Required ZenPacks: ZenPackLib ZenPack, PythonCollector ZenPack
Compatible with Virtana Service Observability (formerly Zenoss Cloud), Virtana Service Dynamics 6.9.0, Service Impact 5.7.2
Version 1.2.1
Released: 2024-05-02
Required ZenPacks: ZenPackLib ZenPack, PythonCollector ZenPack
Compatible with Virtana Service Observability (formerly Zenoss Cloud), Virtana Service Dynamics 6.9.0, Service Impact 5.7.2
Features
The following features are available to help you monitor resources deployed in Google Cloud Platform.
Discovery
The following component types will be automatically discovered through Google Cloud Platform APIs. The components, their properties, and their relationships will be periodically remodeled to provide automatically up-to-date monitoring.
Projects
Each Google Cloud Platform project to be monitored must be added to Virtana. The resulting Virtana "device" equates to this project, and all of the resources within that project become components of the project in Virtana.

Projects
Properties
n/a
Relationships
Regions
Zones
Images
Snapshots
Instance Templates
Kubernetes Clusters
Quotas
Dataflows
All Compute Engine (GCE) components will have the following standard properties.
Properties
Name
Creation Timestamp
Kind
GCE ID
GCE Self-Link
All Kubernetes Engine (GKE) components will have the following standard properties.
Properties
Name
Creation Timestamp
Self-Link
Regions
Regions will only be discovered if the project contains instances in the region.

Properties
Description
Status
Relationships
Project
Zones
Instance Groups
Quotas
Functions
Dataflows
Zones
Zones will only be discovered if the project contains instances in the zone.

Properties
Description
Status
Relationships
Project
Region
Instance Groups
Machine Types
Disk Types
Disks
Instances
Images
Images will only be discovered if they're the source image for at least one disk within the project.

Properties
Description
Family
Disk Size
Archive Size
Status
Relationships
Project
Disks
Snapshots

Properties
Disk Size
Archive Size
Storage Status
Status
Relationships
Project
Source Disk
Instance Templates
Instance templates will only be discovered if they were the template for an instance within the project, or if they're the template for a managed instance group in the project.

Properties
Description
Machine Type
Minimum CPU Platform
Number of Disks
Number of Network Interfaces
Relationships
Project
Instances
Quotas
All project-level and region-level quotas with a limit set will be modeled.

Properties
Metric
Usage
Limit
Relationships
Project or Region
Instance Groups
Instance groups will only be discovered if they contain at least one instance. This includes multi-zone (region) instance groups, single-zone instance groups, and managed and unmanaged instance groups.

Properties
Description
Managed
Multi-Zone
Size
Target Size
Base Instance
Relationships
Region or Zone
Instance Template
Instances
Kubernetes Node Pool
Machine Types
Machine types will only be discovered if used by an instance within the project. Note that it is possible for a machine type of the same name to vary in capabilities from region to region. So you will see multiple machine types of the same name that only vary by their zone.

Properties
Description
Guest CPUs
Shared CPUs
Memory
Maximum Persistent Disks
Maximum Persistent Disk Size
Image Space
Relationships
Zone
Instances
Disk Types
Disk types will only be discovered if used by a disk within the project. Note that it is possible for a disk type of the same name to vary in capabilities from region to region. So you will see multiple disk types of the same name that only vary by their zone.

Properties
Description
Default Disk Size
Valid Disk Size
Relationships
Zone
Disks
Disks
Disks will only be discovered if they're attached to at least once instance within the project.

Properties
Size
Last Attach Timestamp
Last Detach Timestamp
Relationships
Zone
Disk Type
Source Image
Snapshots
Instances
Instances
All instances within the project will be discovered.

Properties
Description
Guest
CPU Platform
Management IP
Network IPs
NAT IPs
IP Forwarding
In Kubernetes
Kubernetes ZenPack Node
Status
Relationships
Zone
Machine Type
Disks
Network Interfaces
Instance Group
Instance Template
Network Interfaces
All instance network interfaces within the project will be discovered.

Network Interfaces: Properties: Network IP, NAT IPs, Access, Access Type: Relationships: Instance
Kubernetes Clusters
All Kubernetes clusters within the project will be discovered.

Kubernetes Clusters: Properties: Cluster Ipv4 CIDR, Node Ipv4 CIDR Size, Services Ipv4 CIDR, Current Master Version, Initial Cluster Version, Logging service, Monitoring service, Endpoint, Network, Subnetwork, Current Node Count, Kubernetes ZenPack Cluster, Status: Relationships: Project, Zones, Node Pools
Kubernetes Node Pools
All Kubernetes node pools within the project will be discovered.

Kubernetes Node Pools: Properties: Version, Initial Node Count, Node Disk Size, Node Image Type, Node Service Account, Node Machine Type, Status: Relationships: Cluster, Instance Groups
Cloud Functions
All Cloud Functions within a region will be discovered.

Cloud Functions
Properties: Full Name, Service, Runtime, Status, Available Memory, Account Email Relationships : Project, Region
Dataflow Jobs
Dataflow Jobs within a project will be discovered with appropriate zGoogleCloudPlatformDataflowJobNamesModeled.

Dataflow Jobs
Properties: Name, Job Type, Current State Time, Create Time, Start Time, Version, SDK Version, Display Name, SDK Support Status Relationships : Project, Region
BigQuery Datasets
BigQuery Datasets within a project will be discovered with appropriate zGoogleCloudPlatformBigQueryDatasetsModeled.

BigQuery Datasets
Properties: Name, Friendly Name, Location, Creation Time, Last Modified Time, Access Relationships : Project

Storage Buckets
Properties: Name, Storage Class, Time Created, Time Updated, Location, Location Type, Lablels Relationships : Project

BigTable Instances
Properties: Full Name, Display Name, Instance Type, Lablels Relationships : Project, BigTable Clusters, BigTable AppProfiles

BigTable Clusters
Properties: Full Name, Default Storage Type, Server Nodes Relationships : Zone, BigTable Instance, BigTable AppProfiles

BigTable App Profiles
Properties: Full Name, Allow Transactional Writes, Cluster Routing Relationships : BigTable Instance, BigTable Cluster

BigTable Tables
Properties: Full Name Relationships : BigTable Instance
Status Monitoring
Many of the discovered resources have a status available via the Google Cloud Platform APIs. All of these are monitored by default by this ZenPack.
In addition to the per-resource-type status values listed below, each of these resource types can also have one of the following non-API status values.
PENDING: Virtana has not yet (or recently) collected status for the resource.
MISSING: Resource no longer exists in Google Cloud, and will likely be removed the next time modeling occurs.
UNKNOWN: An unexpected status value not known to exist for the resource type.
Regions: Status: DOWN, UP: Event: DOWN, MISSING
Zones: Status: DOWN, UP: Event:: DOWN, MISSING
Images: Status: FAILED, PENDING, READY: Event: FAILED
Snapshots: Status: CREATING, DELETING, FAILED, READY, UPLOADING: Storage Status: UNKNOWN, UP_TO_DATE, UPDATING: Event: FAILED
Instances: Status: PROVISIONING, STAGING, RUNNING, STOPPED, SUSPENDING, SUSPENDED, TERMINATED
Kubernetes Clusters: Status: STATUS_UNSPECIFIED, PROVISIONING, RUNNING, RECONCILING, STOPPING, ERROR, DEGRADED: Event: ERROR, DEGRADED
Kubernetes Node Pools: Status: STATUS_UNSPECIFIED, PROVISIONING, RUNNING, RUNNING_WITH_ERROR, RECONCILING, STOPPING, ERROR: Event: RUNNING_WITH_ERROR, DEGRADED
Cloud Functions
Status : CLOUD_FUNCTION_STATUS_UNSPECIFIED, ACTIVE, OFFLINE, DEPLOY_IN_PROGRESS, DELETE_IN_PROGRESS, Event : CLOUD_FUNCTION_STATUS_UNSPECIFIED, OFFLINE, DEPLOY_IN_PROGRESS, DELETE_IN_PROGRESS, UNKNOWN
BigTable Instances
Status : PENDING, MISSING, STATE_NOT_KNOWN, READY, CREATING, RESIZING, DISABLED Event : STATE_NOT_KNOWN
BigTable Clusters
Status : PENDING, MISSING, STATE_NOT_KNOWN, READY, CREATING Event : STATE_NOT_KNOWN, DISABLED
Performance Monitoring
Performance (metric) monitoring is done via the Stackdriver Monitoring API. The following metrics are monitored by default.
Project
BigQuery Execution Time
BigQueryExecutionTime: bigquery.googleapis.com/query/execution_times
BigQuery Scanned Bytes Billed
BigQueryScannedBytesBilled: bigquery.googleapis.com/query/statement_scanned_bytes_billed
BiqQuery Scanned Bytes
BigQueryScannedBytes: bigquery.googleapis.com/query/scanned_bytes
Slot Metrics Known Issues
Since Slot metrics in StackDriver are inconsistent, they are not collected by Virtana. This is documented as 'Known Issues' in the following reference: https://cloud.google.com/bigquery/docs/monitoring
Instances
CPU Utilization
Average: compute.googleapis.com/instance/cpu/utilization
Total Disk Throughput
Read: compute.googleapis.com/instance/disk/read_bytes_count
Write: compute.googleapis.com/instance/disk/write_bytes_count
Throttled Disk Throughput
Read: compute.googleapis.com/instance/disk/throttled_read_bytes_count
Write: compute.googleapis.com/instance/disk/throttled_write_bytes_count
Total Disk Operation Rate
Read: compute.googleapis.com/instance/disk/read_ops_count
Write: compute.googleapis.com/instance/disk/write_ops_count
Throttled Disk Operation Rate
Read: compute.googleapis.com/instance/disk/throttled_read_ops_count
Write: compute.googleapis.com/instance/disk/throttled_write_bytes_count
Total Network Throughput
Received: compute.googleapis.com/instance/network/received_bytes_count
Sent: compute.googleapis.com/instance/network/sent_bytes_count
Total Network Packet Rate
Received: compute.googleapis.com/instance/network/received_packets_count
Sent: compute.googleapis.com/instance/network/sent_packets_count
Firewall Throughput
Dropped: compute.googleapis.com/firewall/dropped_bytes_count
Firewall Packet Rate
Dropped: compute.googleapis.com/firewall/dropped_packets_count
Container CPU Usage (Kubernetes Nodes Only)
CPU Usage: container.googleapis.com/container/cpu/usage_time
Container Memory (Kubernetes Nodes Only)
Total: container.googleapis.com/container/memory/bytes_total
Used: container.googleapis.com/container/memory/bytes_used
Container Memory Faults (Kubernetes Nodes Only)
Major: container.googleapis.com/container/memory/page_fault_count
Minor: container.googleapis.com/container/memory/page_fault_count
Disks
Disk Throughput
Read: compute.googleapis.com/instance/disk/read_bytes_count
Write: compute.googleapis.com/instance/disk/write_bytes_count
Throttled Disk Throughput
Read: compute.googleapis.com/instance/disk/throttled_read_bytes_count
Write: compute.googleapis.com/instance/disk/throttled_write_bytes_count
Disk Operation Rate
Read: compute.googleapis.com/instance/disk/read_ops_count
Write: compute.googleapis.com/instance/disk/write_ops_count
Throttled Disk Operation Rate
Read: compute.googleapis.com/instance/disk/throttled_read_ops_count
Write: compute.googleapis.com/instance/disk/throttled_write_bytes_count
Functions
Invocations: cloudfunctions.googleapis.com/function/execution_count
Total
Ok
Timeout
Error
Execution Times
Active Instances
Memory Use
Network Egress
Dataflow Jobs
Memory Use: dataflow.googleapis.com/job/total_memory_usage_time
MemoryUsageTime (byte-seconds)
Disk Usage: dataflow.googleapis.com/job/total_pd_usage_time
DiskUsageTime (byte-seconds):
CPU Usage: dataflow.googleapis.com/job/total_vcpu_time
Total: (seconds)
Elements: dataflow.googleapis.com/job/element_count
ElementCount
System Lag: dataflow.googleapis.com/job/system_lag
SystemLag: (seconds)
BigQuery Datasets
Stored Bytes
storedBytes: bigquery.googleapis.com/storage/stored_bytes
Tables
tables: bigquery.googleapis.com/storage/table_count
Uploaded Rows
uploadedRows: bigquery.googleapis.com/storage/uploaded_row_count
Storage Buckets
Total Bytes
totalBytes: storage.googleapis.com/storage/total_bytes
Object Count
objectCount: storage.googleapis.com/storage/object_count
Received Bytes Count
receivedBytesCount: storage.googleapis.com/network/received_bytes_count
Sent Bytes Count
sentBytesCount: storage.googleapis.com/network/sent_bytes_count
Last Updated
thirtyDays: objects updated 30 to 60 days ago
sixtyDays: objects updated 60 days ago
BigTable Instances
Cpu Load:
btiCpuLoad: bigtable.googleapis.com/cluster/cpu_load
Cpu Load Hottest Node:
btiCpuLoadHottestNode: bigtable.googleapis.com/cluster/cpu_load_hottest_node
Node Count:
btiNodeCount: bigtable.googleapis.com/cluster/node_count
Disk Load:
btiDiskLoad: bigtable.googleapis.com/cluster/disk_load
Storage Utilization:
btiStorageUtilization: bigtable.googleapis.com/cluster/storage_utilization
Disk Bytes Used:
btiDiskBytesUsed: bigtable.googleapis.com/disk/bytes_used
Storage Capacity:
btiStorageCapacity: bigtable.googleapis.com/disk/storage_capacity
CPU utilization
Google Recommended thresholds: 70% for instances with 1 cluster or multiple clusters and single-cluster routing; 35% for instances with 2 clusters and multi-cluster routing. For instances with more than 2 clusters and multi-cluster routing, see google's threshold guidance.
CPU utilization (hottest node)
Google Recommended thresholds: 90% for instances with 1 cluster or multiple clusters and single-cluster routing; 45% for instances with 2 clusters and multi-cluster routing. For instances with more than 2 clusters and multi-cluster routing, see google's threshold guidance.
BigTable Clusters
Cpu Load:
btiCpuLoad: bigtable.googleapis.com/cluster/cpu_load
Cpu Load Hottest Node:
btiCpuLoadHottestNode: bigtable.googleapis.com/cluster/cpu_load_hottest_node
Node Count:
btiNodeCount: bigtable.googleapis.com/cluster/node_count
Disk Load:
btiDiskLoad: bigtable.googleapis.com/cluster/disk_load
Storage Utilization:
btiStorageUtilization: bigtable.googleapis.com/cluster/storage_utilization
Disk Bytes Used:
btiDiskBytesUsed: bigtable.googleapis.com/disk/bytes_used
Storage Capacity:
btiStorageCapacity: bigtable.googleapis.com/disk/storage_capacity
BigTable Tables
Replication Max Delay:
bttReplicationMaxDelay: bigtable.googleapis.com/replication/max_delay
Replication Latency
bttReplicationLatency: bigtable.googleapis.com/replication/latency
Error Count:
bttErrorCount: bigtable.googleapis.com/server/error_count
Modified Rows Count:
bttModifiedRowsCount: bigtable.googleapis.com/server/modified_rows_count
Server Latencies:
bttServerLatencies: bigtable.googleapis.com/server/latencies
Received Bytes Count:
bttReceivedBytesCount: bigtable.googleapis.com/server/received_bytes_count
Request Count:
bttRequestCount: bigtable.googleapis.com/server/request_count
Returned Rows Count:
bttReturnedRowsCount: bigtable.googleapis.com/server/returned_rows_count
Sent Bytes Count:
bttSentBytesCount: bigtable.googleapis.com/server/sent_bytes_count
Table Bytes Used:
bttTableBytesUsed: bigtable.googleapis.com/table/bytes_used

Billing Monitoring
This Zenpack also supports monitoring of Google Cloud Services for a project. Costs can be separated by region, services and labels. Overview graphs and project-level graphs are available after configuration. All regions and services are not monitored by default. New datasources may need to be created for desired services and regions.Billing monitoring requires some usage of BigQuery so additional Google Cloud Services costs will be present.
Billing Monitoring Configuration
Give the service account JobUser and DataViewer permissions to BigQuery for the billing project.
On the Virtana side you will need to configure two zProperties, zGoogleCloudPlatformBillingTableId and zGoogleCloudPlatformBillingProjectId to start collecting data.
You may also want to configure zGoogleCloudPlatformBillingCostThreshold to setup alerts and events for billing costs.
Label Filters
The ZenPack now provides a way to group and collect Google Cloud Services components on an project based on GCP Labels.
By creating a label filter will allow you to view all components of any type matched by the filter, along with their graphs.
In addition, you can use this Label Filter to view estimated billing information for the group of labels in the Expenses Analysis section. The GCP Label Filters use a special monitoring template, LabelFilter, which is not visible in the device-level monitoring template section,
but is visible if you go to Advanced > Monitoring Templates.From here, you can add modify the template, should you need to do so
Adding Label Filters
You can define a label filter by navigating to your project device and by using the + menu in the lower left part of the screen select "Add GCP Label Filter" .
Using the dialog menu, give your Label Filter a name, and select the label you want to track. You can combine multiple tags with the AND and OR operators.
You can also generate a Component Group based on the Label Filter.
Click Submit when finished. The Label Filter will be visible in the the navigation bar, and the "GCP Label Filters" section.
Incremental Instance Monitoring
Compute instances can be incrementally model on the same interval as zGoogleCloudPlatformStackDriverMonitoringInterval.
Ensure your service account has permissions to retrieve and access logging information. Incremental modeling will add, delete and update
compute instances. Incremental only supports partial modeling and will not retrieve all information. Any information missing will be added on next
full model. Guest Devices will also be created just like normal modeling if configured.
Guest Device Discovery
Guest devices are devices that are created based on instance components that GCP discovers. This facility is mean to simplify creation of Linux/Windows/Other guests that GCP creates. In order for guest devices to be properly created you need to provide two pieces of information:

Set the zGoogleCloudPlatformDiscoverGuests property to True in the GCP device Configuration Properties.
From the Configuration Properties, and open the zGoogleCloudPlatformGuestLabels dialog (at right):
From here you will see two text boxes. The first box is a Label:Value expression. It must be in the form of two simple regular expressions separated by a colon. The following are all valid:
label1:value1
label1.*:value2.*
label.*one:value.*two
The second text box is the Device Class field, which must be filled with a valid path to an existing device class. For example:
/Server/SSH/Linux
/Server/Microsoft/Windows
If the dialog detects any mis-formatted entries it will reject attempts to add that Label-DeviceClass entry.
You can have multiple entries to allow for a broader set of services but only the first match will apply to a given instance, so ensure your order is correct before starting.
Once your zGoogleCloudPlatformGuestLabels entries are set, you need to remodel your GCP device.
If all is correct, Instances whose GCP labels match one in zGoogleCloudPlatformGuestLabels will be scheduled to be created with the associated device class.
When an instance component is removed from GCP, the associated guest device will automatically be removed.
Manual deletion of guest devices is permanent until next modeling cycle occurs.
Note
The GCP ZenPack makes no attempt to ensure credentials are set on guest devices. The default values should be set appropriately.
zGoogleCloudPlatformResetGuestCollector and zGoogleCloudPlatformAutoChangeProdState must be set on GCP device for guest device management.
Expense Analysis
You can track Google Cloud Services estimated usage charges for a project, given label or label group, and grouped by specific services or regions.
In order to set this up, you must create a Label Filter to match the label or label in which you are interested in and then you must configure
exporting billing data to BigQuery as mentioned earlier.

Dynamic View
Project Dynamic View

Dynamic View support is enabled for projects, and all resources that have an impactful relationship to other resources. See the Service Impact and Root Cause Analysis section for more detail on what the specific impact relationships are.
The project-level Dynamic View shows a high-level logical overview of the discovered project's resources instead of the typical (what impacts the project) view because nothing would typically impact the project as a whole.
Service Impact and Root Cause Analysis

When combined with the Virtana Service Dynamics product, this ZenPack adds built-in service impact and root cause analysis capabilities for services running on Google Cloud. The service impact relationships described below are automatically added. These will be included in any services that contain one or more of the explicitly mentioned components.
Impact Diagram
Impact Relationships
Kubernetes node pools impact their Kubernetes Cluster.
Kubernetes clusters impact their associated Kubernetes ZenPack Clusters.
Instance groups impact any associated Kubernetes Node Pool.
Instances impact their associated Guest OS Devices.
Instances impact their associated Kubernetes ZenPack nodes.
Instances impact any Instance Group to which they belong.
Network Interfaces impact their Instance.
Disks impact any Instance to which they're attached.
Zones impact any contained Instances.
Regions impact all Zones in the Region and Functions.
Projects impact all Regions, Dataflows and BigQuery Datasets.

Usage
Creating a Service Account
Adding a Google Cloud Platform Project to Virtana requires a service account with the Project View role. This role allows Virtana to view all resource information within the project, but not make any changes.
Use the following steps to setup a service account.
Open the Google Cloud Console.
Choose the project you want to monitor.
Navigate to the IAM & admin service.
Navigate to Service accounts.
Click Create Service Account.
Enter a name for the account.
Choose the Project / Viewer role.
Select Furnish a new private key.
Select the JSON key type.
Save the JSON document:
Be sure to save the downloaded JSON file to a safe place. Open this JSON file in any text editor. You'll be needing the full values from the project_id, client_email, and private_key keys to add the project to Virtana
Restricted Access
If the monitoring user has restricted access to any part of GCP API, full modeling and monitoring will be restricted!
You must provided specialized Viewer access for each component that needs to be monitored. We recommend using the Viewer role at the project level as we outline above.
Adding a Project
Use the following steps to add a Google Cloud Platform project to Virtana.

Navigate to the Infrastructure page.
Click the Add Devices menu button above the devices grid.
Choose the Add Google Cloud Project... menu option.
Complete the form..
Device Name: Any valid Virtana device name.
Project ID: project_id from the service account's JSON file.
Client Email Address: client_email from the service account's JSON file.
Private Key: private_key from the service account's JSON file.
Guest Devices Use External IP: Select this if you plan to monitor the operating systems running on instances via their NAT IP addresses. Deselect it if you will monitor them via their internal Google IP addresses.
Collector: The Virtana collector responsible for monitoring the project.
Click Add.
Alternatively you can use zenbatchload to add projects from the command line. To do this, you must create a file with contents similar to the following. Replace all values in angle brackets with your values minus the brackets. Multiple projects can be added under the same /Devices/GoogleCloudPlatform section.
/Devices/GoogleCloudPlatform
my-project-3 \
zGoogleCloudPlatformProjectId='<project_id>', \
zGoogleCloudPlatformClientEmail='<client_email>', \
zGoogleCloudPlatformPrivateKey='<private_key>'You can then load the endpoint(s) with the following command.
zenbatchload <filename>
Installed Items
This ZenPack installs the following items into the Virtana system.
Configuration Properties
zCiscoUCSCIMCEventsInterval: Event collection interval in seconds. Default is 60.
zCiscoUCSCIMCPerfInterval: Metric collection interval in seconds. Default is 300.
zCiscoUCSCIMCSSLProtocol: The SSL/TLS protocol used to connect to a CIMC device. With the zProperty you can select one of the following SSL/TLS protocols: SSLv23, TLSv1, TLSv1.2. For the CIMC 3.0 it should be set to SSLv23 or TLSv1.2 protocol, and for the other versions, you can use the TLSv1 protocol. Default is SSLv23.
zCiscoUCSCIMCReuseSessions: Whether to reuse existing sessions during CIMC collection. Default is true.
zCiscoUCSManagerUser
zCiscoUCSManagerPassword
zCiscoUCSManagerPort: Port to use to connect to the UCS Manager or CIMC XML APIs. Default is 443 and typically should not be changed.
zCiscoUCSManagerUseSSL: Whether to use SSL when connecting to the UCS Manager or CIMC XML APIs. Default is true and typically should not be changed.
zCiscoUCSManagerPerfInterval: How often to collect statistics. Default is 300 seconds. This configuration is only used when the reporting interval cannot be modeled from UCS Manager.
Device Classes
/CiscoUCS: Root Cisco UCS device class. Typically devices should not be put in this device class.
/CiscoUCS/UCS-Manager: Device class for UCS Manager endpoints.
/CiscoUCS/CIMC/C-Series: Device class for stand-alone UCS C-Series rack-mount servers.
/CiscoUCS/CIMC/E-Series: Device class for UCS E-Series servers.
Modeler Plugins
zenoss.ucs.CiscoUCSInstanceMap: UCS Manager modeler plugin.
zenoss.ucs.CIMCServer: Stand-alone C-Series and E-Series modeler plugin.
Datasource Types
Cisco UCS XML API: UCS Manager XML API datasource type. For UCS Manager.
UCS CIMC: CIMC XML API datasource type. For C-Series and E-Series.
Note
You can skip the data collection for particular datapoints defined under CIMC XML API datasources with xpath_skip_query property located in the datapoints, use XPath syntax while adding the custom skip rules.
Monitoring Templates
/CiscoUCS (used for UCS-Manager)
General Components
Device
UCSBladeServer
UCSCartridgeServer
UCSChassis
UCSEthPort
UCSFabricEthLanPc
UCSFabricFcoeSanPc
UCSFabricFcSanPc
UCSFabricInterconnect
UCSFanModule
UCSFcPort
UCSHostEthIf
UCSPowerSupplyUnit
UCSProcessorUnit
UCSSharedAdaptor
Pool Components
DASPortPool
EthPortPool
FcPortPool
PerChassisServerPortPool
PerChassisStorageFcPortPool
PerFexServerPortPool
PerFIApplianceEthPortPool
PerFIDASPortPool
PerFINetworkFcPortPool
PerFINetworkPortPool
PerFIServerPortPool
PerFIStorageFcPortPool
SingleChassisServerPortPool
SingleChassisStorageFcPortPool
Capacity Templates
UCSCapBladeServer
UCSCapChassis
UCSCapDevice
UCSCapEthPort
UCSCapFabricEthLanPc
UCSCapFabricExtender
UCSCapFabricFcoeSanPc
UCSCapFabricFcSanPc
UCSCapFabricInterconnect
UCSCapFabricIOCardPort
UCSCapFcPort
UCSCapHostEthIf
UCSCapHostFcIf
UCSCapIOCard
UCSCapMiniChassis
UCSCapRackServer
UCSCapServerIOCardPort
UCSCapServiceProfile
UCSCapVnicEther
UCSCapVnicFc
/CiscoUCS/CIMC (shared for C-Series and E-Series)
Device
Memory
PowerStats
TemperatureStats
PowerSupply
FanModule
Fan
CPU
MemoryArray
MemoryUnit
NetworkAdapter
ExternalInterface
VICAdapter
VICExternalInterface
VICvNIC
VICvBHA
StorageController
RAIDBattery
LocalDisk
VirtualDrive
/CiscoUCS/CIMC/E-Series
MemoryArray
Event Classes
/CiscoUCS
/CiscoUCS/Event
/CiscoUFS/Fault
/Status/Blade
/Status/Chassis
/Change/Set/UCS
Event Class Mappings
LOCAL0-3-SYSTEM_MSG (in /CiscoUCS): Handles syslog messages from UCS Manager.
UCS Events Default (in /CiscoUCS/Event): Handles events from UCS Manager XML API.
UCS Faults Default (in /CiscoUCS/Fault): Handles faults from UCS Manager XML API.
ucs-cimc-configResolveClass (in /Status): Handles polling failures from CIMC XML API.
ucs-cimc-defaultmapping (in /Status): Default handler for faults from CIMC XML API.
ucs-cimc-status (in /Status): Handles status events from CIMC XML API.
Collector Daemons
zenucsevents: UCS Manager events and metrics
zenpython: UCS Capacity metrics and CIMC metrics
Configuration Properties
zGoogleCloudPlatformActivityLogInterval: Polling interval (in seconds) for activity logs. Default 300.
zGoogleCloudPlatformActivityLogSubscriptionName: Subscription name that will be used to pull activity logs. Default none.
zGoogleCloudPlatformBigQueryDatasetsModeled: List of regular expression to match BigQuery Datasets for modeling. Default none.
zGoogleCloudPlatformBillingCostThreshold: GCP Project Billing Cost Threshold for events and alerts in dollars. Default 1000.
zGoogleCloudPlatformBillingProjectId: Project Id of billing data table. Default none.
zGoogleCloudPlatformBillingTableId: BigQuery Table Id to use for retrieving billing data. Default none.
zGoogleCloudPlatformClientEmail: Client email address to use for monitoring. Default None. Required.
zGoogleCloudPlatformComputeMaxResults: Maximum number of results per page for Compute Engine API requests.Default 500.
zGoogleCloudPlatformDataflowJobNamesModeled: List of regular expression to match Dataflow Jobs for modeling. Default none.
zGoogleCloudPlatformFunctionWhitelist: Regular Expression patterns to specify Cloud Function modeling. Default all: [".*"].
zGoogleCloudPlatformGuestUseExternalIP: Use external (NAT) IP for creating and linking guest devices. Default true.
zGoogleCloudPlatformDiscoverGuests: Enable auto-discovery of GCP instance guest devices. Default false.
zGoogleCloudPlatformGuestLabels: Label to DeviceClass association for GCP instance guest devices. Default none.
zGoogleCloudPlatformResetGuestCollector: Allow the guest discovery process to reset guest device collectors during update with GCP Project's collector. Default false.
zGoogleCloudPlatformAutoChangeProdState: Automatically change production states for guests when instance state changes. Default false.
zGoogleCloudPlatformMonitoringPageSize: Maximum number of points per page for Monitoring API requests. Default 100,000
zGoogleCloudPlatformPrivateKey: Private key to use for monitoring. Default none: Required.
zGoogleCloudPlatformProjectId: Project ID to monitor. Default none: Required.
zGoogleCloudPlatformQuotaInterval : Polling interval (in seconds) for quota datasources. Default 300.
zGoogleCloudPlatformStackDriverMonitoringInterval: Polling interval (in seconds) for Stackdriver Monitoring datasources. Minimum 240, Default 300.
zGoogleCloudPlatformStatusInterval: Polling interval (in seconds) for status datasources. Default 300.
zGoogleCloudPlatformBigTableInstancesModeled: Regular Expression patterns to specify BigTable Instance. Default none: [] Required to model BigTable components .
zGoogleCloudPlatformBigTableClustersModeled: Regular Expression patterns to specify BigTable Cluster modeling. Default none: []
zGoogleCloudPlatformBigTableAppProfilesModeled: Regular Expression patterns to specify BigTable AppProfile modeling. Default none: []
zGoogleCloudPlatformBigTableTablesModeled: Regular Expression patterns to specify BigTable Table modeling. Default none: []
Device Classes
/GoogleCloudPlatform: All Google Cloud Platform projects are added to this device class.
Modeler Plugins
GoogleCloudPlatform.Project: Models all components for a Google Cloud Platform project.
Datasource Types
Google Cloud Platform Activity Log Monitoring
Google Cloud Platform Billing Monitoring
Google Cloud Platform Instance Group Monitoring
Google Cloud Platform Quota
Google Cloud Platform Stackdriver Monitoring
Google Cloud Platform Status
Google Cloud Platform Storage Bucket Monitoring
Google Cloud Platform Instance Audit Log Monitoring
Monitoring Templates
/GoogleCloudPlatform
ProjectDevice
BigQuery
CloudFunction
ComputeRegion
ComputeImage
ComputeDisk
ComputeInstance
ComputeInstanceGroup
ComputeSnapshot
ComputeZone
Dataflow
EstimatedCharged
KubernetesNode
KubernetesCluster
KubernetesNodePool
LabelFilters
StorageBuckets
BigTableInstance
BigTableCluster
BigTableTable
Event Classes
/GoolgleCloudPlatform
Event Class Mappings
/Status
gcp-status-api
gcp-status-region
gcp-status-image
gcp-status-snapshot
gcp-status-snapshot-storage
gcp-status-zone
gcp-status-instance
gcp-status-kubernetes-cluster
gcp-status-kubernetes-nodePool
gcp-status-function: {}
gcp-status-bigtable-instance: {}
gcp-status-bigtable-cluster: {}
StackDriver Monitoring
StackDriver Monitoring Configuration
Stackdriver datasources can be customized to various services and metrics. To add a new datasource:
First select a component type and select the Template drop-down.
Click on the + and provide a datasource name and select Stackdriver type.
Edit that datasource
Choose the appropriate API Service.
Then choose the Metric Type from the pulldown.
Choose the Cross-Series Reducer (optional)
Choose the Per-Series Aligner (optional)
Enter a Filter (optional) if required
Choose Aggregation Function under Post Processing
Save
Testing the StackDriver Datasource
You can test the datasource you created (or modified) above by going into the datasource configuration and scroll down to the Test Against a Device area:
Choose a valid GCP device name
Hit the Test button
If all goes well you should see information on:
Requested Parameters
Metrics
Datapoints
If you get an error during the test, you can check:
GCP permissions if indicated
Compatibility with the metrics, aligners, and reducers in the datasource
Adding Data Points to the StackDriver Datasource
Once you have tested your datasource as above you can add data points as indicated in the Testing section above.
Stackdriver Filters
Stackdriver filters allow you to narrow your search by various parameters. Filters are optional. You will find the filters Format for the filters are: key = value. Some examples of filters are:
metric.type = "compute.googleapis.com/instance/cpu/usage_time"
metric.labels.instance_name = "my-instance-name"
project_id = "zenoss-proto-1" and function_name = "HelloDolly"
Notes for Filters:
You don't need to put in a metric.type filter: That is done automatically.
You can have multiple filters joined by "and" as in the 3rd example above.
Stackdriver Reducers
Stackdriver Reducers or Cross-Series Reducers are used to aggregate data according to different algorithms. This is the approach to be used to combine time series. Not all reducer functions may be applied to all time series, depending on the metric type and the value type of the original time series. See https://googleapis.github.io/google-cloud-python/latest/monitoring/gapic/v3/types.html for specific details. In general you should note:
Not all reducer functions may be applied to all time series
You can use the Test button in the datasource UI to validate your reducer
When I doubt, you should go to the Metrics Explorers at Google to validate your reducers and filters at:
Limitations and Known Issues
This ZenPack has the following known limitations and issues:
Adding Project
Adding using the Add Multiple Devices or Add Multiple Devices requires that an IP address or resolvable name be entered for the device. Google Cloud Platform projects don't have an IP or resolvable name, so something arbitrary such as cloud.google.com must be used. It is recommended that the Add Google Cloud Project menu item be used to add projects instead because it doesn't require a resolvable name be entered
Dialogue option may not appear in Firefox Browser.
Upgrades to 1.1.0 and Missing Components
Expenses Analysis and GCP Labels Filters may be missing in UI after upgrading from an older version of the zenpack. If this issue is encountered, restart the zproxy service (by restarting) top-level "Zenoss.resmgr" application in Control Center. It is not necessary to restart the child services.
Model Accuracy
Continuous modeling is not currently supported by this ZenPack. This means that the model seen in Virtana may be up to 12 hours old because it is only updated every 12 hours by default.
Monitoring for GCP Functions is inconsistent when datapoint are sparse or singletons. The graphs will show zero for various cloud function graphs.
Some datapoint values such as "storage/object_count" and "storage/total_bytes" are only reported by google once a day.
Manual Modeling may intermittently fail.
Datasource Timeouts
Datasources for large projects may timeout Intermittently.
Managed Resource Counting
This ZenPack contributes the following to your Managed Resource (MR) count:
GCP Compute Engine instances that aren't already counted as the guest of another monitored resource.
Your GCP project connection — the entry point used to reach your GCP resources — does not count toward your MR total.
Storage buckets do not count as an MR — these are storage, not managed compute resources.
Changes
1.2.2
Fixed a key-naming issue where Compute Engine instance counts were not being recognized toward your Managed Resource total; they are now correctly included. (ZPS-9325)
Your GCP project connection point is excluded from your Managed Resource total, as it is not itself a monitored resource. (ZPS-9335)
Tested with Virtana Service Observability (formerly Zenoss Cloud), Virtana Service Dynamics 6.9.0, Service Impact 5.7.2
1.2.1
Make GoogleCloudPlatform ZenPack compatible with Ubuntu-based CZ 7.2.0 (ZPS-8848)
Tested with Virtana Service Observability, Virtana Service Dynamics 6.7 and Service Impact 5.6.0
1.2.0
Add support for BigQuery. (ZPS-6363)
Add Management of guest device (ZPS-5808)
Add support of Google Cloud Storage (ZPS-6235)
Add support for BigTable (ZPS-6332)
Tested with Virtana Service Observability, Virtana Service Dynamics 6.4.x and Service Impact 5.5.1
1.1.0
Add support for Dataflow Jobs. (ZPS-5801)
Add support for Cloud Functions. (ZPS-5719)
Support "reducer" in Stackdriver Monitoring datasource. (ZPS-5558)
Support "filter" in Stackdriver Monitoring datasource. (ZPS-5559)
Support "group by" in Stackdriver Monitoring datasource
Add support for Instance Group Monitoring (ZPS-3501)
Add support for Billing Monitoring with services and region analysis (ZPS-5807)
Support for tags for all components (ZPS-5809)
Support for Billing reports based on tags and labels (ZPS-6024)
Tested with Virtana Service Observability, Virtana Service Dynamics 6.3.x, Virtana Service Dynamics 6.4 and Service Impact 5.5.1
1.0.2
Fixing compatibility with DynamicView 1.8.0 and Impact 5.5. (ZPS-5666)
Tested with Virtana Service Observability and Virtana Service Dynamics 6.3.x and Service Impact 5.5.1.
1.0.1
Fix false positives for quotas with a limit of 1 and usage of 0. (ZPS-4567)
Fix "too many items" error when modeling instances belonging to multiple instance groups. (ZPS-4695)
Provide links and impacts between GKE components and Kubernetes ZenPack components. (ZPS-4778)
Prevent false modeling changes when nothing changed in modeled project. (ZPS-5207)
Tested with Virtana Service Dynamics 6.3.2, Virtana Service Observability, and Service Impact 5.3.4.
1.0.0
Initial release.
ZenPack Classification |
|
|---|---|
Name | ZenPacks.zenoss.GoogleCloudPlatform |
Applications Monitored | Google's Cloud Platform |
